Peguet 8mm Stainless Steel Square Quick Link – Precision-Forged Maillon Rapide (5/16″)

Description

Product Description

Peguet 8mm (5/16″) Stainless Steel Square Maillon Rapide Quick Link
Square shape: the finest connector when connecting two flat webbing of the same width.
Specifications:

Diameter: 8MM or 5/16″

LT: 53mm

LI1: 19.5mm

LI2: 37mm

HT: 74mm

HI: 58mm

O: 10mm

E: 24mm

T: 11mm

Weight: 87g (0.191 lbs)

Working Load: 550kg (1,212 lbs)

Breaking Load: 2,750kg (6,062 lbs)

Material:

Stainless Steel

Rod: Standard X2 Cr Ni, Mo 17-12-2 (1.4404) AISI 316L

Nut: Standard X2 Cr Ni, Mo 17-12-2 (1.4404) AISI 316L

Rod: custom-made steel used in surface processing, providing complete strength towards traction.

Nut: high safety steel (lead-free, systematic control carried out after drawing through Eddy currents and ultrasounds).

Surface processing made through electrolytic coating on the entire material (rod & nut).
Tightening Torque:
ط F 2,5 3,0 3,5 4,0 5,0 6,0 7,0 8,0 9,0 10,0 12,0 14,0 16,0 18,0 20,0
Torque 0,15 0,30 0,60 0,70 0,80 1,20 2,50 3,00 4,50 7,00 9,00 12,00 18,00 30,00 40,00
Recommendation:

Keep to the working load limit WLL engraved in kg.

Visual check of complete nut screwing compulsory; no thread must be showing.

Maillon Rapide quick links are only to be loaded along the major axis.

Maillon Rapide quick links should be carefully checked at regular intervals. If you are in any doubt about the safety of a quick link after checking, replace it with a new one.

When fastened with a wrench up to the proper tightening torque, Maillon Rapide quick links are considered a permanent connector.

Maillon Rapide should always be fitted with parts made of same material.

When connected with chain, Maillon Rapide quick links should be of the same diameter.

Never connect any Maillon Rapide quick links onto a lifting chain.

Stainless steel Maillon Rapide quick links may be used in salt water.

P.P.E. EN 362 & EN 12275 Standards: Maillon Rapide quick links must be accompanied by user instructions when sold or used as a connector on P.P.E. (Personal Protective Equipment).
