Name: Wichard 4-Inch Long-Eye Bolt with 5/8-Inch (10mm) Shank
Brand: Wichard
SKU: 6495
Availability: InStock

Description

Product Description

Wichard 4″ Long Eye Bolt w/ 5/8″ (10mm) Diameter
Features

Weight – 0.216 Lbs (98 g)

Working Load – 3527 Lbs (1600 kg)

Breaking Load – 5950 Lbs (2700 kg)

A – M10 x 150

B – 5/8″ (16mm)

C – 1 27/64″ (36mm)

D – 9/32″ (7mm)

E – 64/64″ (25mm)

F – 3 15/16″ (100mm)

G – 3 29/64″ (88mm)
Description

A complete range of single piece forged products for fastenings applications

Outstanding working and breaking loads

Available in different sizes

Maximum tightening torque: 36Nm
Applications

Various fastening applications

Towing application

Waterskiing lines attachment
Material

Grade 316L stainless steel
