Name: Wichard 5 5/16" Trigger Snap Shackle with Integrated Swivel
Brand: Wichard
SKU: 2857
Availability: InStock

Description

Product Description

Wichard 5 5/16″ Trigger Snap Shackle w/ Swivel Shackle
Features

Weight – 0.86 Lbs (309 g)

Length – 5 5/16″ (135mm)

Working Load- 9171 Lbs (4160 kg)

Breaking Load- 17630 Lbs (8000 kg)

A – 1 1/16″ (27mm)

B – 3/4″ (19mm)

C – 45/64″ (18mm)

D – 7/16″ (11mm)
Description

HR forged trigger snap shackle with swivel shackle

The opening is made by hand (low load) or by using a release fid

Allows to attach a non spliced sheet.

Free rotation of the snap shackle thanks to the swivel

Outstanding working and breaking loads
Applications

Trigger snap shackle requiring no splicing sheet

Many fastening applications: furling systems, deck fitting…
Material

HR stainless steel 17.4 PH
