Lewmar Size 10 Ocean Hatch with 1-Inch Flange

Description

Product Description

Lewmar Size 10 1″ Flange Ocean Hatch
All sizes suitable for CE Area 2 (Deck, Coach roof, Cockpit and Transom).
Mounting Instructions:
Fit to a flat surface with a maximum tolerance of +/- 1mm. Fastening size at hinge section use (M6 / 1/4″). Fastening size for lower frame use 5mm CSK screw No.10 UNC 2 BA.
Specifications

Lower Frame (in) – 1″ Flange

Acrylic Color – Smoke Grey

Hatch Weight (lb) – 5.77

Acrylic Window Thickness (in) – 3/8
Dimensions

Length X (in) – 12 3/4

Width Y (in) – 12 3/4

Height Z (in) – 1 9/16

Radii R (in) – 2 15/16

Hinge Length HX (in) – 3/16

Hinge Width HY (in) – 5 7/16

Cut-Out Length (Flange) X1 (in) – 10 1/4

Cut-Out Width (Flange) Y1 (in) – 10 1/4

Cut-Out Radii (Flange) R1 (in) – 1 11/16
